- Splices PU and PVC belt up to 3 mm thick and 127 mm wide
- Fits in belts up to 14" in circumference
- 19 mm daylight opening
- Cantilever lower frame and suspended platen
The ali-5 is the latest in Almex lightweight vulcanizers especially designed to join small circumference belts.
This shop style press splices lightweight PU and PVC belts up to 3 mm (0.12”) thick. The custom platen area is 127 mm (5”) wide and is available in custom lengths up to 1066.8 mm (42”) long, according to your application.
The minimum belt circumference size of this press is 350 mm (14”).
19 mm (0.75”) daylight and downstroking provide even pressure up to 40 psi (2.8 kg /cm²) along the length of the platen.
- Suspended lower platen makes insertion and removal of small circumference belts very easy
- Pneumatically pressurized downstroking platen
- Cantilever lower frame
- Accommodates small circumference belts
- Quality Almex Custom Pressure Bag and Platens
- Unitized temperature and pneumatic pressure controls
|Product Code||Total Weight (Metric/Imperial|
|ALI-542-R-40-FCP||431 kg / 950 Lbs.|
- for model shown in photos
